Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals
The Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals makes it easy to control and monitor equipment from almost anywhere. Whether you need to manage gear at a transmitter site, an outstation, or an unmanned post, this compact 1U rackmount unit keeps everything connected and responsive over a standard Ethernet network. It’s built to give you peace of mind, knowing you can trigger alarms or adjust controls remotely with reliability you can trust.
Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals Review
The Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals offers an advanced yet straightforward way to extend control signals across multiple sites. With 16 general-purpose inputs, 16 outputs, and flexible analogue I/O that can be mapped or scaled to match different equipment, it’s designed for professional broadcast and technical environments. Its built-in web server makes setup and control simple, and the status LEDs on both the front and rear panels give you instant feedback at a glance. Whether you’re linking two units together or sending commands from a computer, the RB-IPE ensures fast, reliable communication.
Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals Features
- Remote control of equipment through a simple network connection
- Easy setup with a built-in web server interface
- Clear LED lights that show input and output status at a glance
- Slim 1U rack design saves space while handling big jobs
- Reliable performance for transmitter sites, alarms, and remote stations
- Can map and adjust analogue signals for flexible control options
Sonifex RB-IPE IP Extender for GPIO & Analogue Control Signals Specs
- 16 general-purpose inputs and 16 outputs across RJ45 connectors
- Analogue inputs up to 3.3V, 5V, or 12V with adjustable outputs
- Relay outputs rated for 1A at 30V DC or 0.5A at 125V AC
- Universal power supply 85–264V AC at 47–63Hz, 10W max
- Compact size 19in W x 4.3in D x 1.7in H (1U rackmount)
- Weight 3.5 lbs
