Grace Design m501 Microphone Preamp
Bring out the pure, natural sound of your recordings with the Grace Design m501 Microphone Preamp. Built for those who value clarity over coloration, this compact 500 series preamp lets every detail of your vocals and instruments shine. Whether you’re capturing a delicate acoustic performance or a powerful vocal take, the m501 delivers studio-grade sound with effortless precision.
Grace Design m501 Microphone Preamp Review
The Grace Design m501 takes the trusted performance of the classic m101 preamp and brings it into the 500 series format. Its transformerless design and wide gain range ensure that what you capture is exactly what you hear, with almost zero distortion. The unique ribbon mic mode protects sensitive microphones while enhancing their performance, and the high-impedance input makes plugging in instruments quick and easy. Every part of the m501 is crafted to deliver transparent sound and reliable performance, making it a favorite choice for engineers who demand accuracy from their gear.
Grace Design m501 Microphone Preamp Features
- Captures sound with incredible clarity and detail
- Works beautifully with any type of microphone, from vintage ribbon to dynamic
- Special ribbon mic mode for added protection and better performance
- Built-in high-pass filter to clean up low-end noise
- High-impedance input lets you plug in instruments directly
- Durable front panel with easy-to-read LED indicators
Grace Design m501 Microphone Preamp Specs
- Gain range from 10 dB to 75 dB in 5 dB steps
- Total harmonic distortion under 0.00085% at 20 dB gain
- Frequency response from 3.8 Hz to 288 kHz
- Input impedance 8.1 kΩ (20 kΩ in ribbon mode)
- Hi-Z input impedance up to 5 MΩ
- Maximum output level +27 dBu
- Power consumption 120 mA from ±16V supplies
Grace Design m501 Microphone Preamp Dimensions
- Height: 5.25 in
- Width: 1.5 in
- Depth: 6.6 in
- Weight: 0.7 lbs
