CAD Audio PX5002 500W 2-Channel Power Amplifier
The CAD Audio PX5002 500W 2-Channel Power Amplifier gives your PA or installed sound system plenty of clean, reliable power without taking up much rack space. Its compact design fits neatly into a standard rack, while flexible operating modes make it easy to use in different setups. With built-in protection and smart cooling, the PX5002 is ready for demanding events, venues, and professional audio systems.
CAD Audio PX5002 500W 2-Channel Power Amplifier Review
The PX5002 is a professional Class-D amplifier with two channels that deliver 500 watts per channel at 4 ohms or 300 watts per channel at 8 ohms. It can also provide 1,000 watts in bridged mode at 4 ohms. Balanced XLR inputs, link outputs, and three speakON outputs offer flexible connections, while the 75 Hz low-cut filter and peak limiter help protect your speakers. Its efficient power supply, soft-start design, variable-speed fan, and protection circuits support dependable operation during long sessions.
CAD Audio PX5002 500W 2-Channel Power Amplifier Features
- Compact 1U design saves valuable rack space
- Stereo, parallel, and bridge modes suit different setups
- Built-in limiter helps protect connected speakers
- Smart fan cooling keeps the amplifier running smoothly
- Low-cut filter helps reduce unwanted low frequencies
- Protection circuits help guard against overheating, overloads, and short circuits
CAD Audio PX5002 500W 2-Channel Power Amplifier Specs
- 2-channel Class-D amplifier
- 500W x 2 at 4 ohms
- 300W x 2 at 8 ohms
- 1,000W x 1 bridged at 4 ohms
- Frequency response 20 Hz to 20 kHz
- Signal-to-noise ratio greater than 100 dB
- THD 1% or less
- Input sensitivity 0.775V, 1.0V, or 1.44V
- 2 XLR inputs and 2 XLR link outputs
- 3 speakON speaker outputs
- 115 to 230 VAC, 50/60 Hz
- 1U, 19-inch rackmount chassis
- Dimensions 19 x 9.4 x 1.8 inches
- Weight 9.3 lbs
- Variable-speed fan cooling
